1、down,lipitintoplaceonitsside.Trytohaveatleasttwomenoperatingthemachine,becauseitisverytime-consumingtohaveonemanmovingfromonesideofthemachinetotheothertopressandeject.Butitcanbedonebyonemanifonlyoneisavai1ab1e.Fourpersonsmakeanidealteamforpressing:onefilling,onepressing,oneejecting,andoneremoving.te
2、amoffourcaneasilyproducetwoblocksaminuteifthemixtureispreparedandcloseby.Stickinq.SomesoiIsstickmorethanothers.Anoccasionalcleaningofthecornersofthepressboxwithametalscrapermaybenecessary.Theblocksshouldcomeoutofthepresswithsharpcorners.Stickingcanbeovercomebyslightlymoisteningthepointswhereitoccurs
3、withabitofkeroseneonarag.RotatiwJobs.Onajobwherethereisenoughlabortohaveallthesteps-digging,screening,mixing,loading,pressing,ejecting,andcarrying-goingonatthesametime,itisfairandgoodformoraletorotatethejobseveryhourorso.MaintenanceandRepairs1.ubrication.Al1movingparts(rollers,pins,pressureplate,gui
4、deplates,pistonscylinder,bearingsandsupportsofaxles)shouldbewel1lubricatedeveryfourtoeighthourswithheavyoilorgreasetoinsuresmoothoperationandcutdownonwear(SeeFig.15).Pins.Thepinswhichsecurethepivotshafts,compressionyokeandrolIersshouldbereplacedwhenbrokenbythelargestnailsavai!able,becausetheywilllas
5、tlongerthantheaveragecotterpin.IfCringreplacementsarenotavai!able,brokenCringscanbereplacedbywrappingapieceofwireinthegroove.CleanSurfacee.Theinsideoftheboxandtheundersurfaceofthecovermustbekeptclean.Fig.15-1.ubricationPoints52.Adiustments.TheCINVA-Rampressshouldnotbetamperedwithun-necessarily,butth
6、efollowingsuggestionsmayhelpifthepressproducesfaultyblocks.53.BreaksandCracks.Breaksandcracksarecausedbylooseorin-correctlyadjustedguideplates.54.SideBreaks.(SeeFig.16.)Movetheloweradiustingbolts(GandH)side-vaystowardthehighsideofthebreak(seeFig.1).Ifmoreadjustmentismd-needed,movetheupperadjustingbo
7、lts(RandP)towardthelowsideofthebreak.ThiscansometimesbedoneFig.16-SideBreaksimplybyha11meringtheboltside-ways(withapieceofwood,sothatthethreadswi1notbedamaged)ratherthanbylooseningandtighteningthenuts.Aftertheboltsarehanrmeredover,tightenthenuts.55.EndBreaks.(SeeFig.17.)Movetheguideplateoppositethee
8、ndwherethebreakoccursinwardbyturninglower-14-adjustingboltGorH,dependingontheguideplatetobemoved(seeFig.1)：NOTE:Movingoneendofaguideplateinonedirectionforcestheotherendofthesameplateintheoppositedirection.Ifthisloosensthepistonmuchateitherthetoporthebottomoftheguideplate,theotherendoftheplatemustbem
9、ovedinward.ThefreeplayshouldbecorrectedbecauseitwiHcausetheQiSlOntocracktheblocksbycompressingtheminonedirectioninthecompressioncycle(withtheuppersaddleasthepivotpoint)andinanotherdirectionintheeject,ioncycle(withthelowerrolIersasthepivotpoint).Also,theguideplatesmustbetightenoughagainstthepistontok
10、eepitfromjerkingandjumpingupwardattheendoftheejectioncycle.56.Ifendcrackingisnotstoppedbytighteningtheplatesagainstthepiston,itmaybenecessarytotilttheguideplatesandthepiston,sothatthepressureplatewillbehigherattheendwhichiscracking,Thisisdonebymovingthetopsofbothguideplatestowardthecrackedend.57.Cor
11、nerBreaks.cornerbreakiscausedbyacombinationofm-*asidebreakandanendbreak(seeFig.18).(1)Fixthesidecrackbymov-ingtheboltssideways,asFig.18-CornerBreakinparagraph54(usuallyitisonlynecessarytomovethebottomboltontheendwiththecracktowardtheBidewherethecrackoccurs).(2)Fixtheendcrackbymovingtheloweradjusting
12、boltoppositethecrackingendinwardagainstthepiston,asinparagraph55.58.Taperiq.Taperingiscausedbyincorrectlyadjustedguideplates.59.SideTaper,(SeeFig.19.)Firstmovetheguideplateonthethickersideoutward：thenmovetheotherguideplateinward(seeFig.1).Theguideplatesshouldbekeptparalleltoeachother.Moveboththetops
13、andbottomsofbothguideplatesthesamedistance.B.Fig.19-SideTaper60.EndTaper.(SeeFig.20.)Movethetopsofbothguideplatestoward-the,thinend.Movethebottomsofbothguideplatestowardthethickend.(SeeFig.1).Thetopsshould/bemovedasfarinonedirectionasthebottomsareintheother.1.!izzlFig.20-EndTaper-15-61.62.63.64.65.6
14、6.67.CuringandStackinutheBlocks.Thecuringoftheblocksisanotherimportantstepwhichmustbetakenwithcare.Tobecomecarelessatthispointcouldruinal1thecarefulworkthathasgonebefore.Themoistureintheblocksmustcomeoutslowlyandevenly.ITheblocksshouldhelaidonflat,unwarped,cleanplankswideenoughtosupportthefullwidtho
15、ftheblocks(seeFig.22).Ifsuchtoardsarenotavailable,theblocksshou1dbeplacedonsmoothgroundcoveredwithpaperorleavessothattheywillnotbeindirectcontactwiththeground.Theblocksshouldnotbevushedintoanotherpositionafterbeinpplaced.Ifitisnecessarytomovetheblocksatthispointwhentheyareveryweak,Fig.22.-Blockastac
