1、病理学经典病理学经典图片集图片集Classical Photograph Of Pathology共和国二十一世纪第五个生日即将到来的时共和国二十一世纪第五个生日即将到来的时刻，精心制作了这个图片集，其中涉及了大刻，精心制作了这个图片集，其中涉及了大量精美的、高质量的图片，并附带了大量而量精美的、高质量的图片，并附带了大量而且详尽的文字说明。值六一儿童节即将到来且详尽的文字说明。值六一儿童节即将到来之际，把它献给祖国，也献给奋战在医疗一之际，把它献给祖国，也献给奋战在医疗一线的战友。线的战友。2005.05.212005.05.21 Esophageal Varices 第一部分第一部分Gro
2、ssly,esophageal varices appear as tortuous,dilated,blue veins running along the long axis of the esophagus.This is a photograph of the actual slide in your class set.Note the markedly dilated veins in the submucosa and in the muscularis propria of the esophagus.These dilated varices often cause pres
3、sure atrophy and ulceration of the overlying mucosa,as has happened in this case.The subsequent inflammation of the submucosa causes erosion of the thin wall of the varices with subsequent rupture.The large varix noted by the arrow communicates directly with the lumen and has probably ruptured in th
4、e past.It is now thrombosed.Shows thrombosis of a large submucosal varix.Note the ulceration of the overlying mucosa(arrow)and inflammation of the submucosal stroma.Squamous Cell Carcinoma of the Esophagus 第二部分第二部分Gross:This is an example of an ulcerated squamous cell carcinoma of the esophagus.It d
5、iffers from a benign peptic ulcer of the esophagus in that it is a much larger lesion and rather than being sharply punched-out,it has irregular borders.Note the perforation in the center.Is a low power view of the histologic section in your class set.(M=mucosa;Sm=submucosa;Mp=muscularis propria).Th
6、e intact mucosa is to the left of the arrow;the ulcerated carcinoma(C)is to the right.Is taken at the juncture(arrow head)of the normal mucosa(M)and the ulcerated carcinoma(C)and it shows another common feature of esophageal cancer.The gross margins of the cancer are often misleading because the tum
7、or frequently spreads longitudinally in submucosal lymphatics(double arrows).Is a section taken through the full thickness of the esophageal wall.Carcinomas of the esophagus are typically deeply infiltrating lesions and this one has extended through the muscularis propria(arrows).Shows nests of mali
8、gnant squamous cells within the submucosa.This is a moderately differentiated squamous cell carcinoma in that there is keratin production.The malignant cells show a common feature of malignancy,namely altered polarity.The differentiating squamous cells within the submucosal nests cannot slough kerat
9、in to the luminal surface.Instead the keratin accumulates in the center of the nests as spherical keratin pearls(arrow).Shows the moderately differentiated squamous cell carcinoma with keratin pearls at higher power.Mitotic figures are usually common in malignant tumors and often they are abnormal.T
10、his is a tripolar mitosis and if you look carefully you can see 3 mitotic spindles.Chronic Peptic Ulcer of the Stomach 第三部分第三部分Gross:Chronic peptic ulcers are typically small(less than 4 cm in diameter),round,sharply punched-out lesions with perpendicular walls and a clean base.Fibrous contracture o
11、f the base of the ulcer may cause puckering of the surrounding mucosal folds such that they radiate away from the ulcer in spoke-like fashion.Is a low power view of the gastric ulcer in your class set.The ulcer(U)lies between the arrows.The intact,but chronically inflamed,gastric mucosa(M)is on eith
12、er side.Note that the base of the ulcer extends all the way to the serosa of the stomach.Large arteries(A)are present at the base of the ulcer.Erosion into one of these large arteries could result in massive hematemesis.Is a low power view of the full thickness of the gastric wall in the region of t
13、he ulcer.This ulcer shows ongoing necrosis and inflammation as well as fibrous repair and the classic zones of Askenazy are readily apparent.A represents the superficial layer of necrotic debris and acute inflammation.Just below this superficial layer is a zone of active granulation tissue(B)which i
