1、 QWIN$MIN QWIN$MAX将坐标原点设置在物理坐标点(x,y):CALL SETVIEWORG(x,y,t)其中(x,y)为新原点的物理坐标,t为XYCOORD 结构体类型的变量。TYPE xycoord INTEGER(2)xcoord !x坐标 INTEGER(2)ycoord !y坐标END TYPE xycoord 1设置颜色result=SETCOLORRGB(color)result=SETBKCOLORRGB(color)result=SETTEXTCOLORRGB(color)color为Integer(4)型,一般用16进制表示颜色取值。要使设置的背景色发生作用,须
